项目计划

Thanks to their remarkable material features, girth gears made of ADI** can have less than half the weight of girth gears made of conventional materials that offer the same performance and safety. Project planning for girth gears by SEW-EURODRIVE is therefore an important requirement for creating customer benefits. The high degree of segmentation ensures that individual customer requirements can be met in an ideal way.

Applications

示例：磨坊 /应用程序尺寸示例

– Power rating: up to approx. 15 MW

– Diameter: up to approx. 16 m

– Assembly: flange

– Speed of rotation: high (10 to 20 min-1)

Example: rotary kiln / application size examples

– Power rating: up to approx. 1 MW

– Diameter: up to approx. 9 m

– Assembly: leaf springs

– Speed of rotation: low (1 to 2 min-1)

Possible scope of delivery

– Segmented girth gears

– Drive pinion and, if required, pedestal bearing

– Fastening parts for the girth gear: mounting springs or mounting flange

– Main gear unit

– Motors

– Auxiliary drives

– Lubrication system

– Foundation and base frame

– Couplings and covers

– Condition monitoring

– Installation as well as startup of the whole drive system

5.1 Gearmotors with inverter

MOVIMOT

186

5.3 Gearmotor with motor starter

MOVI-SWITCH

202

Field distributors and fieldbus interfaces

190

5.2 Energy-efficient mechatronic drives IE4

5.4. Decentralized extra-low voltage servo drive

CMP.. ELVCD

203

DRC.. electronic motors

192

Mechatronic MOVIGEARdrive system

194

Installation topologies

- With SNI controller

196

- With SEW-EURODRIVE system bus controller

197

- Binary

198

- With AS-Interface

199

-NEW:Centralized: with control cabinet inverter

200
