Modular CMSM.. electric cylinders
CMSMB50 – 71 series / AP (axially parallel)
Electrical data
Type |
CMSMB63/AP and |
|||
CMP63S |
CMP63M |
CMP63L |
||
Max. torque Nm |
11.1 |
11.11) |
11.11) |
|
Standstill torque Nm |
2.9 |
5.3 |
7.1 |
|
Mechanical data
Rated speed nN |
3 000 min-1 4 500 min-1 6 000 min-1 |
||
Spindle type |
KGT2)25×6 |
||
Max. continuous feed force N |
2 100 |
3 500 |
5 000 |
Peak feed force N |
10 000 |
10 000 |
10 000 |
Stroke lengths mm |
60 / 100 / 160 / 180 / 200 / 400 / 600 |
||
Max. speed mm/s |
450 |
450 |
450 |
1)Max. permitted torque
2)Ball screw
