Features

– Powerful drive inverter for dynamic applications with synchronous and asynchronous motors in the power range 0.55 to 315 kW

– Great diversity of applications due to extensive expansion options with technology and communication options

Line connection

Power range in kW

200 / 240 V / 3-phase

1.5 – 37

400 / 500 V / 3-phase

0.55 – 315

Standard design

The units are equipped with IPOSplusintegrated positioning and sequence control as standard and can be expanded by the options available. “00” at the end of the type designation indicates

the standard design.

Technology version with application modules

In addition to the standard version, these units include the technology functions “electronic cam” and “internal synchronous operation”. The application version is indicated by “0T” following the type designation.

The application version units also provide access to the application modules, the standardized control programs to solve sophisticated technical drive tasks, such as synchronized applications, positioning, flying saw, and winding.

优势的应用程序模块

– High functionality and user-friendly user interface

– Only the parameters needed for the application have to be entered

– Guided parameterization instead of complicated programming

- 没有冗长的培训或熟悉，这意味着快速的项目规划和启动

– Control of all motion functions is performed directly in MOVIDRIVEB

– Decentralized concepts can be implemented more easily

safety

功能安全

MOVISAFE:

Integrated functional safety

Standard design Safe Torque Off (STO) PL d according to EN 13849-1

For information on operating explosion-proof motors with our inverter technology, refer to page 141.
