Sprockets tooth widthB112 mm Sprockets tooth widthb111,8 mm Sprockets tooth widthB234,6 mm Sprockets tooth widthB357,4 mm
CHAIN
Pitch 19,05 mm
Inner width 12,7 mm
Roller Ø 11,91 mm
r
D1
dmde
dp
D1
dm
dedp
D1
dm
C
b1b1
B2B3
AA
CHAIN SPROCKETS ASA 60 pitch 3/4” x 1/2”
MATERIALC 45 UNI 7845
B1 |
|||
A |
|||
Z |
de |
dp |
PART NUMBER |
dm |
D1 |
A |
kg. |
PART NUMBER |
dm |
D1 |
A |
kg. |
PART NUMBER |
dm |
D1 |
A |
kg. |
10 |
71,54 |
61,64 |
11106010 |
42 |
12 |
30 |
0,38 |
11206010 |
42 |
12 |
45 |
0,58 |
11306010 |
42 |
16 |
65 |
0,86 |
11 |
77,51 |
67,61 |
11106011 |
45 |
12 |
30 |
0,50 |
11206011 |
47 |
16 |
50 |
0,80 |
|||||
12 |
83,49 |
73,61 |
11106012 |
45 |
12 |
30 |
0,64 |
11206012 |
53 |
16 |
50 |
1,01 |
11306012 |
53 |
20 |
70 |
1,47 |
13 |
89,49 |
79,59 |
11106013 |
60 |
14 |
35 |
0,80 |
11206013 |
59 |
16 |
50 |
1,24 |
11306013 |
59 |
20 |
70 |
1,78 |
14 |
95,50 |
85,61 |
11106014 |
60 |
14 |
35 |
0,97 |
11206014 |
65 |
16 |
50 |
1,45 |
11306014 |
65 |
20 |
70 |
2,16 |
15 |
101,52 |
91,63 |
11106015 |
60 |
14 |
35 |
1,16 |
11206015 |
71 |
16 |
50 |
1,73 |
11306015 |
71 |
20 |
70 |
2,52 |
16 |
107,54 |
97,65 |
11106016 |
75 |
16 |
35 |
1,34 |
11206016 |
77 |
20 |
50 |
2,03 |
11306016 |
77 |
20 |
70 |
2,93 |
17 |
113,56 |
103,67 |
11106017 |
75 |
16 |
35 |
1,53 |
11206017 |
83 |
20 |
50 |
2,35 |
11306017 |
83 |
20 |
70 |
3,44 |
18 |
119,59 |
109,71 |
11106018 |
75 |
16 |
35 |
1,61 |
11206018 |
89 |
20 |
50 |
2,70 |
11306018 |
89 |
20 |
70 |
3,91 |
19 |
125,63 |
115,75 |
11106019 |
80 |
16 |
35 |
1,70 |
11206019 |
95 |
20 |
50 |
3,06 |
11306019 |
95 |
20 |
70 |
4,43 |
20 |
131,67 |
121,78 |
11106020 |
80 |
16 |
35 |
1,84 |
11206020 |
100 |
20 |
50 |
3,45 |
11306020 |
100 |
20 |
70 |
4,96 |
21 |
137,71 |
127,82 |
11106021 |
80 |
16 |
35 |
2,35 |
11206021 |
100 |
20 |
50 |
3,69 |
11306021 |
100 |
20 |
70 |
5,41 |
22 |
143,75 |
133,86 |
11106022 |
90 |
20 |
40 |
2,45 |
11206022 |
100 |
20 |
50 |
3,96 |
11306022 |
100 |
20 |
70 |
59,7 |
23 |
149,79 |
139年,90年 |
11106023 |
90 |
20 |
40 |
2,56 |
11206023 |
110 |
20 |
50 |
4,50 |
11306023 |
110 |
20 |
70 |
6,64 |
24 |
155,84 |
145,94 |
11106024 |
90 |
20 |
40 |
2,67 |
11206024 |
110 |
20 |
50 |
4,81 |
11306024 |
110 |
20 |
70 |
7,21 |
25 |
161,88 |
152,00 |
11106025 |
90 |
20 |
40 |
2,79 |
11206025 |
120 |
20 |
50 |
5,40 |
11306025 |
120 |
20 |
70 |
7,97 |
26 |
167,93 |
158,04 |
11106026 |
90 |
20 |
40 |
3,08 |
11206026 |
120 |
20 |
50 |
5,73 |
|||||
27 |
173,98 |
164,09 |
11106027 |
90 |
20 |
40 |
3,21 |
11206027 |
120 |
20 |
50 |
6,05 |
|||||
28 |
180,03 |
170,13 |
11106028 |
95 |
20 |
40 |
3,34 |
11206028 |
120 |
20 |
50 |
6,43 |
|||||
30 |
192,14 |
182,25 |
11106030 |
95 |
20 |
40 |
3,62 |
11206030 |
120 |
20 |
50 |
7,18 |
SIMPLES DOUBLE TRIPLE
CAD drawings available on our site
Quantity, availability and prices on B2B Chiaravalli
25
CHAIN SPROCKETSASA 801
r
CHAIN SPROCKETS ASA 80 pitch 1” x 5/8”for roller chains in compliance with DIN 8188 - ISO/R 606 - ANSI B 29.1
pitch 1” x 5/8”C
CHAIN SPROCKETS
Tooth radiusr327 mm
Radius widthC3,2 mm
de
dp
D1
dmde
dp
D1
dm
dedp
D1
dm
